Audio Technica LP5X Direct Drive Manual Turntable
HomeStore

Audio Technica LP5X Direct Drive Manual Turntable

Audio Technica LP5X Direct Drive Manual Turntable

Audio Technica AT-LP5X Fully Manual Turntable

  • Direct-drive, low noise motor
  • Fully manual operation with three speeds: 33-1/3, 45 and 78 RPM
  • AT-VM95E Dual Moving Magnet stereo cartridge (black) with replaceable stylus
  • Lightweight AT-HS6 headshell
  • J-shaped tonearm, modeled after original Audio-Technica designs from the 1960s and ’70s, is engineered to minimize tracking errors
  • Switchable MM/MC built-in pre-amplifier and line enables connection to components with or without a dedicated phono input
  • Anti-resonance, die-cast aluminum platter
  • Heavy rubber damping mat for improved low-frequency reproduction
  • AC adapter handles AC/DC conversion outside of the chassis, reducing noise in the signal chain
  • Elegant matte black finish
  • Includes dual RCA (male) to dual RCA (male) stereo cable, 45 RPM adapter, USB cable
  • Included dust cover and mounting hardware

Building on Audio-Technica’s analog heritage and over 50 years of Japanese audio design, the AT-LP5X features upgraded technology while keeping the contemporary style and acclaimed performance of its predecessor, the AT-LP5.

The LP5X retains the J-shaped tonearm, a design inspired by the classic Audio-Technica models of the 1960s and ’70s, and features a metallic gimbal suspension system and precision bearings to mitigate tracking errors. The tonearm also includes an adjustable counterweight and anti-skate control and comes fitted with a lightweight (9.3g) AT-HS6 headshell and the black AT-VM95E Dual Moving Magnet stereo cartridge.

Constructed of anti-vibration damping materials with heavy-mass metal chassis inserts, the AT-LP5X turntable has been designed to limit low-frequency acoustical feedback. Its precision-machined, die-cast aluminum platter is powered by a direct-drive, low-noise motor, ensuring stable, on-axis rotation at 33-1/3, 45 and 78 RPM. A 5 mm thick rubber-damping mat, which isolates from low frequency feedback while providing a highly stable surface for all LP formats, tops the platter.

The AT-LP5x features a built-in switchable MM/MC phono/line preamp that enables it to connect directly to a computer, home stereo, powered speakers and other components that have no dedicated turntable input. The selection of MM/MC cartridges allow for an easy upgrade to a moving coil with additional equipment. The turntable is also equipped with a USB output for direct connection to a computer.

Audio Technica AT-LP5X Fully Manual Turntable Specs

  • Type: 3-speed, fully manual operation
  • Motor: DC motor
  • Drive Method: Direct Drive
  • Speeds: 33-1/3 RPM, 45 RPM, 78 RPM
  • Turntable Platter: Die-cast aluminum
  • Starting Torque: > 1.0 kgf.cm
  • Braking System: Electronic brake
  • Wow and Flutter: < 0.2% WRMS (33 RPM) at 3 kHz
  • Signal-to-Noise Ratio: > 50 dB
  • Output Level:
    • PHONO: 4.0 mV nominal at 1 kHz, 5 cm/sec
    • LINE: 250 mV nominal at 1 kHz, 5 cm/sec
  • Phono Pre-Amp Gain:
    • MM: 36 dB nominal, RIAA equalized
    • MC: 56 dB nominal, RIAA equalized
  • USB Function: A/D: - 16 bit 44.1 kHz or 48 kHz USB selectable; Computer interface: USB 2.0 compliant Windows 7 or above, MAC OS X or above
  • Power Supply Requirements: 100-240V AC, 50/60 Hz
  • Dimensions: 450.0 mm (17.72") Ă— 352.0 mm (13.86") Ă— 157.0 mm (6.18") (W Ă— D Ă— H)
  • Weight: 7.3 kg (16.1 lbs.)
  • Accessories Included:
    • AT-VM95E Dual Moving Magnet stereo cartridge (black) with replaceable stylus
    • AT-HS6 lightweight headshell
    • AC adapter
    • Dual RCA (male) to dual RCA (male) stereo cable
    • 45 RPM adapter
    • USB cable
    • Dust cover with hinges, Rubber mat, Platter, Counterweight, Headshell (AT-HS6) with VM stereo cartridge (AT-VM95E), Dust cover hinges, USB cable (1.9 m (6.2')), RCA audio cable (approx. 1.0 m (3.3')), AC adapter (approx. 1.5 m (4.9') (AD-SE1220KZ)
  • Tonearm Type: Static balanced J-shaped tonearm
  • Effective Arm Length: 247 mm
  • Overhang: 17 mm
  • Tracking Error Angle: Less than 3°
  • Applicable Cartridge Weight: 15 to 20 g (including headshell)

User Manual
Quick Start Guide
